The Goodman GSX16 16 SEER Air Conditioner is the latest high efficiency 16 SEER Air Conditioner from Goodman and provides a mix of performance, efficiency and value unmatched in the industry. The GSX16 uses the environmentally friendly refrigerant R-410A and features the unique Goodman sound control top design for quiet operation. The coil is made of rifled refrigeration-grade copper tubing and corrugated aluminum fins in a design that maximizes surface area. In addition, the unit has an attractive louvered metal guard that protects the coil from damage plus a powder-paint finish that provides premium durability and improved UV protection.

Standard Features:

• R-410A environmentally friendly refrigerant
• Factory-installed liquid line filter dryer
• 850-RPM condenser fan motor
• High-efficiency scroll compressor
• Copper tube/aluminum fin coil
• Service valves with sweat connections and gauge ports
• Contactor with lug connection
• Ground lug connection
• ARI Certified; ETL Listed

Description

The Goodman AWUF310516 is a wall-mounted, multi-speed air handler with a check flowrater. It has a top-of-the-line, all-aluminum evaporator coil. It comes with a wall-hanging bracket, for a faster installation process.

This Goodman air conditioner comes from the AWUF line of wall-mounted air handlers. It features a blower cooling capacity of 1.5-2.5 tons with a nominal cooling rating of 30,000 BTU/h. It has rust-resistant nickel chromium heating elements that feature an electric heat capability of 5 kW. For effective cooling, this air handler uses a direct drive, multi-speed PSC motor that allows for air volume variation.

This wall-mounted air handler comes with many impressive features that make it a great choice for your home. This model features a large chassis with a front return only. A built-in filter rack with included filter makes for healthier air quality. Plus, a thermoplastic drain pan with bottom primary and secondary drain connections creates better control over condensate and moisture created by this unit.

Features

• Suitable for use with refrigerants R-410A and R-22
• Equipped with a check flowrater for cooling-only and heat pump operation
• Direct-drive, multi-speed motor allows air volume variation for heating and cooling
• Sequence-controlled, rust-resistant nickel chromium heating elements of 3, 5, 8, and 10 kW
• Factory-installed pull-type disconnect
• Aluminum tube coils on all models
• AHRI Certified
• ETL Listed
• Thermoplastic drain pan with bottom primary and secondary drain connections
• Built-in filter rack (filter included)
• Large chassis (2½- and 3-ton units)

Description

A specially formulated super-hydrophobic (water repelling) product in a convenient aerosol package for field service. The non-conductive formula has numerous applications in the management of water on non-food, non-potable water surfaces for the HVAC/R trade; surfaces that are not exposed to ongoing abrasion (hand and foot traffic).

• Slows ice formation on refrigeration coils/cold plates

• Provides added corrosion resistance to coils

• Improves corrosion resistance to system components. Examples include circuit boards, filter-driers, flow control valves, equipment covering, etc.

• Provides added corrosion protection of solder connections on low voltage circuit boards

• Self-cleaning properties reduce rate of grime on outdoor coils

• Reduces rate of bacterial growth on non-food, non-potable water surfaces

• Improves water dispersion in condensate pans

• Many other applications!

• Blower Motor: Multi Speed - PSC
• Brand: Goodman
• CFM: 1,005
• Energy Source: Electric
• Liquid Line: 3/8"
• Max Breaker Size: 35 amps
• Min. Breaker Size: 30.1 amps
• Model: AWUF310516
• Nominal Capacity: 1.5 Ton - 2.5 Ton
• Product Depth: 21"
• Product Height: 36"
• Product Weight: 107 lbs.
• Product Width: 24"
• Refrigerant: R410A or R22
• Suction Line: 3/4"

Directions

This product must be used in accordance to the following directions by HVACR professionals only.

1. Disconnect all power to the equipment before use. Do not spray near sparks, heat or open flame. Discontinue the use of power tools during use. Do not smoke while applying product.
2. Shake well before use. Use outdoors or in a well-ventilated area. Keep area ventilated until fumes are gone. Avoid breathing of fumes during application.
3. Ensure surface is clean and mostly to fully dry before applying. After a coil cleaning, the surface needs to be blown dry with an inert gas to remove excess moisture from the surface before applying Nu-Shield.
4. From a distance of 6-12 inches, spray a light coat on the surface, but no more beyond it being visibly wet. In other words, ‘Wet It and Forget It’. Contents in the canister will cover approximately 100 square feet. Depending on ambient conditions, allow a minimum of 20 minutes for Nu-Shield to dry on surface. Ensure surface appears visually dry and fumes are gone from the area before turning on power to equipment.

Note: Product needs to be applied after each coil cleaning. For best results, especially in corrosive environments, the product should be reapplied annually.

10 Year All Parts Warranty
